Technical Data

  • Bore sizes: 8 mm, 12 mm, 20 mm, 25 mm, 40 mm
  • Stroke lengths: 2.5 mm to 200 mm (depending on model)
  • Forces at 4-10 bar: 2.04 kgf to 128.2 kgf (push), 1.5 kgf to 107.7 kgf (pull)
  • Load capacity: Dynamic 32 kgf to 670 kgf, Static 60 kgf to 1477 kgf
  • Mounting options: End mount, base mount, thin side mount
  • Options: Flow controls, hydraulic seals, multi-position and multi-piston configurations

BSC guided Ball Slide Cylinders

BSC guided Ball Slide Cylinders are pneumatic cylinders with integrated ball guides, designed for precise linear movements in industrial automation. These cylinders offer a compact design, high load capacity, and smooth movements thanks to recirculating ball guides. They are available in BSC1000 and BSC2000 series, with various mounting options and stroke lengths.

Advantages

  • Smooth and precise linear movements
  • Compact design for space-saving
  • High load capacity and long life
  • Flexible mounting options for various applications
  • Options for multi-axis systems and custom configurations
